| Specification of M2M Industrial GPRS DTU serial to RS232 RS485 4IO |
| |
|
| Model No. |
CM510-62G |
| Cellular Parameters |
|
| Item |
Content |
| Cellular |
GPRS industrial wireless module |
| Standards and frequency bands |
GSM/GPRS 850/900/1800/1900MHz |
| GPRS mobile station class B meet GSM phase 2/2+ |
| GPRS multi-slot class 10,class 12 |
| Coding scheme |
CS1~CS4 |
| Communication bandwidth |
Theoretical bandwidth ： 85.6kb/s (upload/ download) |
| Transmit power |
Class 4 （2 W @850/900 MHz）
Class 1 （1 W @1800/1900MHz） |
| Receiver sensitivity |
<-107dBm |
| Hardware system |
|
| Item |
Content |
| CPU |
Industrial high-performance processor |
| MMU |
CPU with MMU memory management unit, can prevent memory overflow exception |
| FLASH |
256Mbits |
| SDRAM |
256Mbits |
| Operating System |
|
| Item |
Content |
| Operating System |
Using real-time operating system with complete TCP/UDP protocol stack, memory management System unit, strongly real-time feature, upgrades fast, stable system; or embedded UCOS operating system |
| Interface Type |
|
| Item |
Content |
| Serial port |
1 RS485 interface/ 1 RS232 serial port |
| Data bit: 8 bit |
| Stop bits: 1bit |
| Parity: no parity |
| Serial speed: 300bps ~ 115200bps |
| Flow Control: None flow control |
| Indicator |
kinds of indicator to show single, fault, online ect. |
| Antenna Interface |
Standard SMA female interface, 50 ohm; optional |
| 3M/5M/10M/15M antenna extension cable, meet the different needs of customers |
| UIM interface |
1.8V/3V/5V standard putter user card interface, built-in 15KV ESD protection |
| Power supply |
|
| Item |
Content |
| Supply voltage |
Wide voltage design, DC 5V to the DC32V power supply directly to the device; and built-in power supply over-voltage protection and reverse current protection |
| Standard power |
DC9V/1.5A |
| Supply |
| Current while Communicating |
Average communication current : 52mA @ +9 VDC; |
| Communicating instantaneous peak current: 120mA @ +9 VDC |
| Standby current |
Standby average current: <30mA @ +9 VDC |
| Physical features |
|
| Item |
Content |
| Shell |
Metal shell: metal case, anti-radiation, anti-interference; shell and system security isolation, lightning protection design; meet the power requirements of safety regulations; protection rating IP41; particularly suit for harsh industrial control environments. |
| Product dimensions |
92*62*22mm（not including the antenna and the fixed parts） |
| Packing Size |
298x226x60mm |
| Weight |
0.41kg |
| Other parameters |
|
| Item |
Content |
| Operating temperature |
-40ºC ~+85ºC |
| Storage Temperature |
-45~+90ºC |
| Relative Humidity |
95%(No condensation) |
