ATC-820 RS-485 to USB Converter
USB TO SERIAL CONVERTER ATC-820
RS 485 TO USB CONVERETER
- Operational system virtual serial port driver.
- Support remote wake-up and power Management.
- Every time same COM number when use 1 MBPS data transfer rate.
- USB Specification rev.1.1/2°0 compliant Operational system virtual serial port driver.
- Automatic flow control for RS485 Half Duplex.
- MaximumRS-485 cable length : 1200 m
- Support the RS485 Serial interface
- Maximum number of devices in the RS485 network: Half Duplex to 32 devices
- Power: from the USB port.
- RS-485 bus protection: 600W.
- USB connection: Mini-B connector. 100cm cable with the module.
- RS-485 connector: DB9M or RJ-45 type accepting
- ABS enclosure: 67 x 30 x 24 mm(not include cable)
USB TO SERIAL CONVERTER ATC-820
RS 485 TO USB CONVERETER
- Operational system virtual serial port driver.
- Support remote wake-up and power Management.
- Every time same COM number when use 1 MBPS data transfer rate.
- USB Specification rev.1.1/2°0 compliant Operational system virtual serial port driver.
- Automatic flow control for RS485 Half Duplex.
- MaximumRS-485 cable length : 1200 m
- Support the RS485 Serial interface
- Maximum number of devices in the RS485 network: Half Duplex to 32 devices
- Power: from the USB port.
- RS-485 bus protection: 600W.
- USB connection: Mini-B connector. 100cm cable with the module.
- RS-485 connector: DB9M or RJ-45 type accepting
- ABS enclosure: 67 x 30 x 24 mm(not include cable)
| Computer interface | : USB V1.1/2.0 Plug and Play |
| Support | : Windows 98/ME/XP/2000/CE‚ MAC & Linux |
| Trans. rate | : from 300 bps to 1Mbps |
| Signal Indication | : Sending data(red) and receiving data(green) LED |
| Supply | : From the USB port |
| Bus protection | : 600W |
| Working Environment | : 0 to 70°C, 10 to 90% relative humidity, non-condensing. |
| Consumption | : <100 mA. |
