15 plus
- Provides voltage, Current outputs
- Provides Analogue Transducer output and loop power
- Measures voltage, current and loop current
- Most Precise & useful tool in field calibration
- Auto Power Off disable function
- Auto Power Off facility
- High Accuracy of 0.05%
- Display
: 6 Digits LCD
- Output Provided
- DC Voltage
: 0 – 200mV to 50V
- Resolution : 0.1mV, Accuracy : ±0.02%
- DC mA
: 0 – 50mA
- Resolution : 1mA, Accuracy :
±0.02%
- Frequency
: 0 – 10KHz
- Resolution : 0.01Hz, Accuracy : ±2
Counts
- Measure range
- DC voltage
: 0 – 10V
- Resolution : 10µV, Accuracy : ±0.02%
- DC Current
: 0 – 20mA
- Resolution : 1µA, Accuracy : ±0.02%
- Frequency
: 0 – 10KHz
- Resolution : 0.01Hz, Accuracy : ±2%
- Pulse
: 0 – 10KHz
- Resolution : 1cyc
- Loop Current
: 0 to 24V
- Accuracy : ±10%
