03
- Simulates thermo – Resistance and resistance output
- Measures thermo-resistance and resistance
- °C and °F scales selectable
- Suitable for field use
- High Accuracy of 0.05%
- Display
: 5 Digits LCD
- Outputs Provided :-
- Resistance Range
: 0 - 400Ω
- Resolution : 0.1Ω
- Accuracy : ±0.05%
- PT-100 Sensor :
-200°C to 850°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Cu50 Sensor
: -200°C to 150°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Measuring Range
:-
- Resistance
: 0 TO 400Ω
- Resolution :
0.1Ω
- Accuracy : ±0.05%
- PT – 100 Sensor
: -200°C to 850°
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Cu50 Sensor
: -50°C to 150°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Simulates thermo – Resistance and resistance output
- Measures thermo-resistance and resistance
- °C and °F scales selectable
- Suitable for field use
- High Accuracy of 0.05%
- Display
: 5 Digits LCD
- Outputs Provided :-
- Resistance Range
: 0 - 400Ω
- Resolution : 0.1Ω
- Accuracy : ±0.05%
- PT-100 Sensor :
-200°C to 850°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Cu50 Sensor
: -200°C to 150°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Measuring Range
:-
- Resistance
: 0 TO 400Ω
- Resolution :
0.1Ω
- Accuracy : ±0.05%
- PT – 100 Sensor
: -200°C to 850°
- Resolution : 0.1°C
- Accuracy : ±0.05%
- Cu50 Sensor
: -50°C to 150°C
- Resolution : 0.1°C
- Accuracy : ±0.05%
